EEG - Classes: 1320 class

Introduced	1969-1972
Manufacturer	English Electric Australia, Rocklea Works, Brisbane, Queensland.
Running Numbers	1320-1344
Number Built	25
Information	All exported to Tasmania, see ZC class

Locomotive Status
Status	Total
Scrapped	4
1322, 1324, 1335, 1339.	4
Reclassified	21
Total	25

Engine	English Electric 12CSVT MKII
Main Generator	English Electric 822/16J
Auxiliary Generator	English Electric 755
Traction Motors	English Electric 548 x 6
Locomotive Brakes	Air, Rheostatic
Train Brakes	Air
Wheel Arrangement	Co-Co

	Imperial	Metric
Gauge	3ft 6in	1067 mm
Minimum Curve	264 ft 0 in	80467 mm
Length	51 ft 6 in	15687 mm
Width	9 ft 3 in	2820 mm
Height	12 ft 4½ in	3772 mm
Weight	88½ tons	89.8 tonnes
Fuel Capacity	1200 Gallons	5455 litres
Power Rating	1950 / 1795 HP	1454 / 1339 kW
Tractive Effort (Start)	62,000 lbs	276 kN
Tractive Effort (Cont)	50,400 lbs at 10¾ mph	224 kN at 17.4 km/h
Speed	60 mph	96 km/h

An overview of the history of '1320 class' locomotives will appear here

Click on Thumbnails below to see a larger image. [ 28 available ]

1270/1300/1320 class and a consist of bulk grain wagons towards Pinkenba. The rail bridge that the train has crossed was constructed in 1957 as part of the quadruplication of the Ipswich line. The bridge is unusual in that there has never been an official naming ceremony. It is flanked by the Albert Bridge (rail bridge, out of picture to the left) built in 1895, and the Walter Taylor Bridge (in background, vehicular traffic) completed in 1937.
